| مكان المنشأ: | صنع في الصين |
| اسم العلامة التجارية: | Infinity Machine Inc. |
| إصدار الشهادات: | ISO |
| رقم الموديل: | سلسلة IE60 |
| الحد الأدنى لكمية: | 1 |
|---|---|
| الأسعار: | Negotiate |
| تفاصيل التغليف: | ورقة شفافة + إسفنجة + كرتونة خشبية |
| وقت التسليم: | 20-30 يوما بعد تأكيد الطلب |
| شروط الدفع: | تي/تي |
| القدرة على العرض: | 200 مجموعة شهريًا |
| اسم المنتج: | غرفة اختبار الأشعة فوق البنفسجية | نموذج: | سلسلة IE60 |
|---|---|---|---|
| نطاق درجة الحرارة: | RT + 20 ℃ ~ 70 ℃ | نطاق الرطوبة: | ≥90٪ ر |
| المعيار المطبق: | ISO 4892-3 、 ISO 11507 ؛ ASTM D4329 、 D499 、 D4587 、 D5208 、 G154 、 G53 ; | ميزة: | التشغيل التلقائي لمراقبة المعدات ، دورة الاختبار التلقائية ، توفير العمل ، تحسين كفاءة الاختبار. |
| بنية مربع: | الصناديق الداخلية والخارجية: يتم استخدام الفولاذ المقاوم للصدأ SUS304# في الصناديق الداخلية والخارجي | حامل العينة: | لوحة رؤية الإطار الأساسي من الألومنيوم، 24 قطعة |
| قوة: | الكترونية | ضمان: | 1 سنة |
UV weathering test chamber uses fluorescent ultraviolet lamps that best simulate the UV spectrum of sunlight, and combines temperature control and humidity supply devices to compare the high temperature, high humidity, condensation, dark rain cycle and other factors that cause discoloration, brightness, strength decline, cracking, peeling, pulverization, oxidation and other damage to the material in sunlight (UV segment). At the same time, through the synergistic effect between ultraviolet light and moisture, the single light resistance or single moisture resistance of the material is weakened or failed, so it is widely used to evaluate the weather resistance of the material.
| Parameter | IE6002 | IE6002A |
|---|---|---|
| Temperature range | RT+20℃~70℃ | |
| Humidity range | ≥90%RH | |
| Temperature fluctuation | ±0.5℃ | |
| Temperature uniformity | ≦1.0℃ | |
| Center distance inside the lamp | 70mm | |
| Distance between specimen and lamp center | 50±3mm | |
| Modulator tube | UVA-340 L=1200/40W, 8pcs | UVB-313 L=1200/40W, 8pcs |
| Irradiance | Adjustable within 1.2W/m² | Adjustable within 1.0W/m² |
| Ultraviolet wavelength | 315-400nm | 280-315nm |
| Effective irradiation region | 900*210mm | |
| Irradiated blackboard temperature | 50℃~70℃ | |
| Internal dimension: W*H*D (mm) | 1140*400*390 | |
| Outside box size: W*D*H (mm) | 1300*500*1360 | |
| Box structure | Indoor and outdoor boxes: SUS304# stainless steel | |
| Sample holder | Aluminum frame type base frame vision plate, 24pcs | |
| Standard sample size | 75*290mm | |
| Safety protection device | Leakage circuit breaker control circuit, overload, short circuit alarm, over temperature alarm, water shortage protection | |
| Power supply | AC220V, 50Hz, 5KW | |
UV Test Chamber will be securely packaged in a wooden crate to prevent any damage during transportation. The crate will be sealed and labeled with the product information for easy identification.
